RoboCap
RoboCap
Wearable cap for egocentric vision and motion data collection
RoboCap
RoboCap
Wearable cap for egocentric vision and motion data collection
Egocentric Vision for Robotics
Capture first-person perspective with 4 wide-angle environment cameras and 2 downward-facing cameras. Generates datasets linking human gaze with surrounding scenes.
10+ hours of data capture
256GB eMMC storage supports synchronized, long-duration data collection.
Note: We continuously refine RoboCap to deliver the best possible version of the product. As a result, the unit you receive may include minor cosmetic updates, branding refinements, or design enhancements compared to the product photos, while maintaining the same core specifications, performance, and functionality.
FAQs
To start recording, connect a power bank to the device’s power supply port using a Type-C cable. The device will begin recording automatically, indicated by a solid green light. To stop recording, disconnect the Type-c cable.
The device records video from six cameras in MP4 format, and data from three IMUs in DB format.
Connect the device to your computer with a USB-C cable. Recording will automatically stop, and a solid red light will appear. The device will then function like a USB drive, allowing you to open it on your computer and copy all recorded files directly.
The headband has an adjustable strap at the back. You can loosen or tighten it to fit comfortably based on your head size.
The device consumes about 4W on average. For example, a 12,000mAh power bank (44.4Wh) provides roughly 11 hours of use: 44.4Wh ÷ 4W ≈ 11.1 hours.
The port closer to the forehead is for data transfer. The port closer to the back of the head is for the power supply.
